Low Pressure 1000 PSI 2 Piece Stainless Steel Ball Valve 316 Double Ferrule Forged

Brand Name : AFK

Model Number : BV

Certification : CE

Place of Origin : China

MOQ : 1~10

Price : Negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 200PC

Delivery Time : 15Day

Material : Stainless Steel

Port size : Standard

Pressure : 1000psi

Standard or nonstandard : Standard

Media : Water,Gas,Oil

Application : General

Size : 1/4"~3/4"

Color : Silver

Body material : Stainless Steel

Valve type : 2 way

Contact Now

Low Pressure Stainless Steel 1000 Psi 316 Double Ferrule Forged Compression Ball Valve

Instrument Ball Valve

2PC Ball Valve-1000PSIG

Characteristics

Black handle with arrow indicates flow direction

End connection available with AFK tube end,BSPT or NPT male thread

Low Pressure 1000 PSI 2 Piece Stainless Steel Ball Valve 316 Double Ferrule Forged

 	 			Features Low Pressure Ball Valve
 			1 			two pieces cold drawn bar body
 			2 			body material stainless steel SS316/316L
 			3 			Max. allowed working pressure 1000psig (69bar)
 			4 			with Fluororubber O-ring and PTFE packing
 			5 			100% factory tested

 	 			Features of Ball Valve
 			Item 			part descrption 			Qty. 			Material
 			1 			handle 			1 			nylon
 			2 			Locking Nut 			1 			SS304
 			3 			Spring washer 			1 			SS304
 			4 			washer 			2 			SS304
 			5 			gland packing 			2 			PTFE
 			6 			stem 			1 			SS316/316L
 			7 			body 			1 			SS316/316L
 			8 			ball 			1 			SS316/316L
 			9 			seat 			2 			PTFE
 			10 			body o-ring 			1 			Fluororubber
 			11 			end cap 			1 			SS316/316L
  	 			Ordering Information
 			C- 			2 			BV- 			S6- 			02 			A- 			1P
 			classification 			product type 			Vavle type 			material 			size(fractional) 			size(metric) 			connection type 			Max.working pressure
 			C:valve 			2:2PC 			BV:2 way ball valve 			S6:SS316 			04:1/4" 			6:6mm 			A:AFK tube end 			1P:1000Psi
 			  			  			  			S6L:SS316L 			06:3/8" 			8:8mm
 			  			  			  			  			08:1/2" 			10:10mm
 			  			  			  			  			012:3/4" 			12:12mm
 			  			  			  			  			  			18:18mm
